Fluke 8845A User Manual

Remote Operation
Ranging in 8842A Emulation Mode
115
Table 41. 8842A Virtual Range Mapping
Function 8842A Range # 8842A Range Value 8845A/88446A Range
VDC
1 200 mVdc 1 Vdc
2 2 Vdc 10 Vdc
3 20 Vdc 100 Vdc
4 200 Vdc 1000 Vdc
5 1000 Vdc 1000 Vdc
8 20 mVdc 100 mVdc
VAC
1 200 mVac 1 Vac
2 2 Vac 10 Vac
3 20 Vac 100 Vac
4 200 Vac 1000 Vac
5 700 Vac 1000 Vac
Ohms (2W)
1 200 Ω 1 kΩ
2 2k Ω 10 kΩ
3 20 kΩ 100 kΩ
4 200 kΩ 1 MΩ
5 2 MΩ 10 MΩ
6 20 MΩ 100 MΩ
IDC
4 200 mAdc 1 Adc
5 2 Adc 3 Adc
ADC
5 2 Aac 3 Aac

Fluke 8845A Specifications

General

Frequency Range	3 Hz to 300 kHz
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	100 μA to 10 A
Resistance Range	100 Ω to 100 MΩ
Resistance Accuracy	0.01 %
Display	5.5 digit
Connectivity	RS-232
AC Current Range	100 μA to 10 A
Frequency Accuracy	0.01 %
Dimensions	88 mm
AC Voltage Accuracy	±(0.06% + 0.03%)
Power Supply	100 V to 240 V AC, 47 Hz to 63 Hz
