DSP-4000 Series
Users Manual
A-2
Table A-1. Tests Supported by Standard Link Interface Adapters
Standard or Test
DSP-LIA011
Basic Link
DSP-LIA012
Channel
TIA Cat 3, 5, 5N, and 5E Basic Link
X
TIA Cat 3, 5, 5N, and 5E Channel X
TIA TSB-75 MUTO Link
X
X
ISO11801 Channel Class C, D X
ISO11801 Permanent Link Class C, D X
ISO Link Class C, D XX
EN 50173 Class C, D XX
Aus/NZ Class C and D Basic Link
X
Aus/NZ Class C and D Channel
X
IEEE 10/100/1000BASE-T X
X
TokenRing, All
XX
TP-PMD
XX
All coaxial standards
X
1
Impulse noise monitor and tone generator
XX
Traffic monitoring on twisted pair cable Optional
DSP-LIA013 only
Hub port locator and hub port capabilities test Optional
DSP-LIA013 only
Optical power and loss measurements using a
DSP-FOM Fiber Optic Meter
2
XX
1. All coaxial testing requires the RJ-45 to BNC adapter.
2. Fiber test standards are supported by optional Fiber Test Adapters.
