Battery Status
The test tool displays a message when its battery voltage or the remote battery
voltage is low. Table 2-7 shows the battery status messages and what you should
do if a battery message appears.
Note
To ensure continued operation while charging the battery, always
connect the ac adapter/charger when the message WARNING
RECHARGEABLE BATTERY VOLTAGE IS LOW appears.
Table 2-7. Battery Status Messages
Message Displayed What You Should Do
WARNING RECHARGEABLE BATTERY
VOLTAGE IS LOW.
Connect the ac adapter/charger.
RECHARGEABLE BATTERY VOLTAGE
IS TOO LOW TO OPERATE.
Turn the test tool off and connect the ac
adapter/charger. If the tool does not operate
when you turn it on, turn it off again and allow
the battery to charge for about 30 minutes.
WARNING REMOTE BATTERY VOLTAGE
IS LOW.
Connect the ac adapter/charger to the remote.
WARNING REMOTE BATTERY
VOLTAGE IS TOO LOW TO OPERATE.
Connect the ac adapter/charger to the remote.
You might need to charge the battery for a short
time before the remote will operate.
INTERNAL DATA STORAGE BATTERY
VOLTAGE IS LOW.
Have the lithium battery replaced at a Fluke
Networks Service Center.
Battery Status Display
To see the charge level of the main unit’s NiMH battery, turn the rotary switch to
SPECIAL FUNCTIONS; then select Battery Status. To see the charge
level of the remote’s battery, connect the remote to the main unit; then use ! to
toggle the display.
