Fluke Datapaq Reflow Tracker User Manual

12 Basic Hardware REFLOW TRACKER
Barriers for DP5 Logger Standard, 6-channel, DP5x60
These barriers also fit Q18 standard 6-channel logger, DQ1860.
TB2015 – Most reflow soldering processes including lead-free
Temp °C 100 150 200 250 280
Duration (mins) 32 16 13 10 9
Dimensions Height Width Length Weight
25 mm 133 mm 210 mm 0.7 kg
1.0 in. 5.2 in. 8.3 in. 1.5 lb
TB2064 – Low-height thermal barrier
Temp °C 100 150 200 250 280
Duration (mins) 25 12 9 8 6
Dimensions Height Width Length Weight
20 mm 133 mm 210 mm 0.6 kg
0.8 in. 5.2 in. 8.3 in. 1.3 lb
Part of the range of Datapaq thermal barriers for the Datapaq DP5 logger.
