14 Basic Hardware REFLOW TRACKER
Barriers for DP5 Logger Narrow, 6-channel, DP5x62
These barriers also fit Q18 narrow 6-channel logger, DQ1862.
TB2020 – Low-height thermal barrier
Temp °C 100 150 200 250 280
Duration (mins) 25 13 10 8 7
Dimensions Height Width Length Weight
28 mm 84 mm 241 mm 0.5 kg
1.1 in. 3.3 in. 9.5 in. 1.1 lb
TB2021 – Most reflow soldering processes including lead-free
Temp °C 100 150 200 250 280
Duration (mins) 36 18 13 11 10
Dimensions Height Width Length Weight
35 mm 84 mm 241 mm 0.65 kg
1.4 in. 3.3 in. 9.5 in. 1.4 lb
Barriers for DP5 Logger, 12-channel, DP5x12
TB2100 – Low-height thermal barrier
Temp °C 100 150 200 250 280
Duration (mins) 25 13 10 8 7
Dimensions Height Width Length Weight
28 mm 133 mm 243 mm 0.69 kg
1.1 in. 5.2 in. 9.6 in. 1.5 lb
TB2101 – Most reflow soldering processes including lead-free
Temp °C 100 150 200 250 280
Duration (mins) 36 18 13 11 10
Dimensions Height Width Length Weight
35 mm 133 mm 239 mm 0.77 kg
1.4 in. 5.2 in. 9.4 in. 1.7 lb
