Unpacking
3
Unpacking
The fiber modules come with the accessories listed below.
If something is damaged or missing, contact the place of
purchase immediately.
DTX-MFM2 Multimode Fiber Modules
•
Two DTX-MFM2 Fiber Modules for testing at 850 nm
and 1300 nm
•
Two 62.5/125 µm multimode test reference cords,
2 m, SC/SC
•
Two gray mandrels for 62.5 /125 µm fiber with 3 mm
jackets
•
Two red mandrels for 50 /125 µm fiber with 3 mm
jackets
•
DTX-MFM2/GFM2/SFM2 Fiber Modules Users Manual
DTX-GFM2 Multimode Fiber Modules
•
Two DTX-GFM2 Fiber Modules for testing at 850 nm
and 1310 nm
•
Two 50/125 µm multimode test reference cords, 2 m,
SC/SC
•
DTX-MFM2/GFM2/SFM2 Fiber Modules Users Manual
DTX-SFM2 Singlemode Fiber Modules
•
Two DTX-SFM2 Fiber Modules for testing at
1310 nm and 1550 nm.
•
Two 9/125 µm singlemode test reference cords, 2 m,
SC/SC
•
DTX-MFM2/GFM2/SFM2 Fiber Modules Users Manual
Note
The test reference cords and connector adapter
types provided are suitable for testing SC-
terminated links. Other test reference cords and
adapter types are required for other connector
types or 50 /125 µm fiber. Many are available as
accessories from Fluke Networks.
