LS-1310/1550
Laser Source
8
C13+
Z2
R20
Z5
R12 R31
R2
BT1+
BT1-
TP2
TP1
R29
R39
R40
nu02f.eps
Figure 2. Calibration Measurement and Adjustment Points for SN ≥ 79130000
