Battery Type and Life: AA (2); 400 hours continuous with
alkaline; 200 hours continuous with zinc chloride
Shock, Vibration: 1 m drop at 15 °C to 35 °C (59 °F to 95 °F)
per ANSI/ISA-S82.01-1994 and EN 61010-1: 1993. Sinusoidal
vibration per MIL-PRF-28800F for a Class 2 instrument
(5 Hz to 55 Hz, 3 g maximum).
Surge Protection: T5-600 6 kV per IEC 1010-1, 1990-09;
T5-1000 8 kV per IEC 1010-1, 1990-09
Enclosure Rating: IP 52 per IEC 529, no vacuum applied
RF Field Specification: 0.5 % full scale + (specified accuracy)
at 3 V / m; Amps: >100 MHz, performance unspecified.
Safety: Complies with ANSI/ISA-S82.01-94 for use in
Overvoltage category III (CAT III) locations, UL3111, CSA/CAN
C22.2 No.1010.1-92, and EN61010-1: 1993.
EMC: EN 50081-1, EN 50082-1
Certifications:
Accuracy is specified for 1 year after calibration, at 18 °C to 28
°C (64 °F to 82 °F) with relative humidity to 90 %. AC
conversions are ac-coupled, average responding, and calibrated
to the rms value of a sine wave input.
Accuracy specifications are given as follows:
± ( [ % of reading] + [number of least significant digits] )
Temperature coefficient of 0.1 x (specified accuracy) / °C for
<18 °C or >28 °C (< 64.4 °F or > 82.4 °F)
Function
T5-600
Range
T5-1000
Range Resolution Accuracy
K 600 V rms 1000 V rms 1 V ± (1.5 % + 2 digits)
L 600 V 1000 V 1 V ± (1 % + 1 digit)
?
100.0 A 100.0 A 0.1 A ± (3 % + 3 digits)
e 1000 Ω 1000 Ω 1 Ω± (1 % + 2 digits)
Input Protection
Function
Input Impedance
(nominal)
T5-600 T5-1000
K
1 MΩ, <100 pF ac-coupled 600 V rms 1000 V rms
L
1 MΩ, <100 pF 600 V rms 1000 V rms
e
>2.6 kΩ 600 V rms 1000 V rms
Function Open Circuit Test Voltage Short Circuit Current
e 2.4 V dc (nominal) <600 µA
