Thermal Imagers
Using the Menu
5
Table 2. Features and Controls (cont.)
Item Description
9 SD memory card compartment
10 Retractable Lens Cover
11 Visual camera
12 Thermal (IR) camera
13 Focus control
14 Trigger
Using the Menu
The menus, coupled with the three softkeys (c, a, and d), provide access for
setting features (date, time, language, units, backlight and spot temperatures),
thermal image display, and saving and viewing stored images.
To bring up the menu, press a. The text above each function softkey (c, a,
and d) corresponds to that softkey throughout all menu screens.
Press a to open and cycle through the menus.
The menu will disappear several seconds after the last press of a softkey.
Changing the Displayed Language
To change the display to present information in another language:
1. Press a until the F1 softkey label reads Language.
2. Press the softkey labeled Language.
3. Press the softkey labeled Up or Down to move the cursor to the desired
language.
4. Press the softkey labeled Back/Done to set the units.
Setting the Imager Clock
The Imager has an internal real-time clock that holds the date and time of day.
