FLYGT C3356 - Page 64

D-connection, 6-pole terminal, 1 cable; 6x5 and 7x5 series
SUBCAB
GC
GC
L2 L3L1
GC
3~
V2
W1
W2
V2
U2
W2
U1
V1
V1 W1U1
U2
L2L3L1
Figure 26: Schematic diagram
Connection for 6X5 and 7X5 drives units.
W1
V1
U1
W2
U2
V2
L2
L3
L1
Figure 27: Drive units 605/615, 665/675;
705/715, 735/745, 765/775
Installation
60 C3300/6x5, C/R3231, C3240, C3306, C3312, C3351, C3356, C3400, C3501, C3531, C3602, C3800 Installation,
Operation and Maintenance Manual
