Element Alto15
© 2003 - 2017 ... Naviter d.o.o.
Setting ALT1 to GPS or FL:
1. Press and hold SET
2. In the sub-menu you have entered, press and hold MENU.
3. Use the arrow keys to switch between GPS or flight level.
3.2.3 Alternative altitude display
Toggle between displaying ALT1 and ALT2 by pressing A1 / 2. When ALT2 is toggled, your Element will
not necessarily display the label ALT2, instead it will indicate whichever ALT2 configuration is presently
selected. You can configure ALT2 to show any of four different values using the Flight Settings menu.
1. Press and hold MENU, then use the arrow keys to select Flight Settings.
2. Press OK.
3. Use the arrows to select Alt2 mode and press OK.
4. Then select your preferred ALT2 mode.
5. Press OK.
6. Press ? to return to the Main Setup Menu.
These are the four available choices for ALT2:
GPS altitude
: (The label GPS appears beside the altitude reading.) Note that you cannot adjust ALT2
when you have selected this option. ALT2 will only display the current GPS altitude.
Flight Level
: (The label FL appears beside the altitude reading.) Note that you cannot adjust ALT2
when you have selected this option, because the Flight Level display is always based on a standard
atmospheric pressure value of 1013.25 hPa.
ALT1 m/ft inverse
: (If ALT1 is displayed in metres, then ALT2 displays true altitude in feet. The label
ALT1 remains beside the altitude reading but the units change.) Note that you can adjust this value.
Adjusting ALT2 in this mode will automatically adjust ALT1 as well.
Relative altimeter
: (The label ALT2 appears beside the altitude reading. Note that you can adjust this
value.
Adjusting ALT 2
Make sure you have selected ALT2 to be displayed by pressing the A1 / 2 key.
1. Press and hold SET
2. Use the arrow keys to adjust the ALT2 value.
3. Confirm with OK.
When ALT2 is in relative mode you can zero it or set it to GPS:
1. Press and hold SET
2. In the sub-menu you have now entered, press and hold the MENU key .
3. Use the arrow keys to switch between 0 or GPS.
When ALT2 is set to ALT m/ft inverse, your altitude displayed is the same, just in different units. You
therefore can only adjust ALT1 as described above.
When ALT2 is set to GPS or Flight Level, you have not further options of adjusting the value.
