PARTS
This list contains replaceable parts used in your replace. When ordering parts, follow the
instructions listed under Replacement Parts on page 43 of this manual.
BVC-36YA BVC-42YA BVC-50YA
KEY
NO. PART NO. DESCRIPTION QTY.
1 ** Face Assembly • • • 1
2 ** Firebox Bottom Assembly • • • 1
3 ** Firebox Bottom • • • 1
4 ** Firebox Surround • • • 1
5 ** Outer Dome Assembly • • • 1
6 ** Insulation Pan Support • • • 1
7 ** Insulation Pan • • • 1
8 ** Top Insulation • • • 1
9 110285-03 Fireplace Top Assembly, 36" • 1
110285-02 Fireplace Top Assembly, 42" • 1
110285-01 Fireplace Top Assembly, 50" • 1
10 23490SA Standoff • • • 4
11 ** Fireplace Surround Assembly • • • 1
12 109720-02 Clearance Spacer • • • 6
13 117891-01 Fireplace Handle Bracket • • • 4
14 20042 Outside Air Cover Plate • • • 2
15 21171 Gas Conduit Cover • • • 4
16 109752-01 Conduit One • • • 2
17 109752-02 Conduit Two • • • 2
18 ** Firebox Support • 2
** Firebox Support • • 1
19 ** Firebox Legs • • • 2
20 ** Inner Dome Assembly • • • 1
21 ** Smoke Shield • • • 1
22 ** Damper Control Bracket • • • 1
23 109457-03 Screen 36" • 2
109457-02 Screen 42" • 2
109457-01 Screen 50" • 2
24 20806 Screen Rod 36" • 2
110146-03 Screen Rod 42" • 2
110146-02 Screen Rod 50" • 2
25 120441-01 Decorative Andiron • • • 2
26 125358-01 Limit Switch Plate • • • 1
27 14574 Limit Switch 280º F • • 1
106543-01 Limit Switch 300º F • 1
PARTS AVAILABLE NOT SHOWN
108055-11 Wire Harness • • • 1
see page 40 Firebrick Walls • • •
** Not a eld replaceable part.
