KEY
NO. PART NO. DESCRIPTION QTY.
1 125116-01 Left Leading Brick 36" Red • • 1
125118-01 Left Leading Brick 42"/50" Red • • • • 1
2 125116-02 Right Leading Brick 36" Red • • 1
125118-02 Right Leading Brick 42"/50" Red • • • • 1
3 125042-01 Hearth 36" Red • • 1
125043-01 Hearth 42" Red • • 1
125044-01 Hearth 50" Red • • 1
4 124216-01 Rear Stacked 36" Red • 1
124228-01 Rear Herringbone 36" Red • 1
125419-01 Rear Stacked 42" Red • 1
125431-01 Rear Herringbone 42" Red • 1
125443-01 Rear Stacked 50" Red • 1
125455-01 Rear Herringbone 50" Red • 1
5 124218-01 Right Stacked 36" Red • 1
124230-01 Right Herringbone 36" Red • 1
125445-01 Right Stacked 42"/50" Red • • 1
125433-01 Right Herringbone 42" Red • 1
125457-01 Right Herringbone 50" Red • 1
6 124220-01 Left Stacked 36" Red • 1
124232-01 Left Herringbone 36" Red • 1
125447-01 Left Stacked 42"/50" Red • • 1
125435-01 Left Herringbone 42" Red • 1
125459-01 Left Herringbone 50" Red • 1
7 124134-01 Side Retainer 36"
(Included with Firebox)
• • 4
124134-02 Side Retainer 42"/50"
(Included with Firebox)
• • • • 4
124134-04 Side Retainer 36" Stainless
(Included with Firebox)
• • 4
124134-05 Side Retainer 42"/50" Stainless
(Included with Firebox)
• • • • 4
8 124134-03 Rear Retainer
(Included with Firebox)
• • • • • • 2
124134-06 Rear Retainer Stainless
(Included with Firebox)
• • • • • • 2
9 120848-01 Ash Brick Red • • • • • • 1
PARTS
This list contains replaceable parts used in your rebox. When ordering parts, follow the
instructions listed under Replacement Parts on page 43 of this manual.
MKB-36SS-RA MKB-36SH-RA MKB-42SS-RA MKB-42SH-RA MKB-50SS-RA MKB-50SH-RA
