Woofers / midranges mounting
Woofer
Set up fixing clips to accept the
fixing screws later (fig.1). Set up the
fixing ring, ensuring it lines-up with
the fixing clip positions.Fix the foam
gasket to the back of the drive unit
chassis. Fix with the screws provided.
Add the grille, clip on the screws
head, then push in place. To remove
the grille, pull on the tongue.
Midrange
Set up fixing clips to accept the
fixing screws later. (fig.1). Set up the
fixing ring, ensuring it lines-up with
the fixing clip positions. Fix with the
screws provided. Add the grille, clip
on the screws head, then push in
place. To remove the grille, pull on
the tongue.
11
English
