Subwoofers installation
Utopia Be line subwoofers are
tailored to be installed in small
enclosures to allow their installation
in the front of the vehicle. The aim
is to bring bass frequencies from the
back to the front of the vehicle in
order to have a better staging. It also
aims at allotting critical frequencies
(50 to 100Hz) to real speakers tuned
to have a maximum of neutrality,
dynamic and behaviour.
Subwoofers installation
Each subwoofer kit comes complete
with its fixing kit and foam gasket.
Cut out and place the driver into
position and attached securely in
place.
13 WS mounting
Place fixing clips to accept the fixing
screws later. (fig.X). Place the fixing
ring (fig. 1), ensuring it lines-up with
the fixing clip positions. Fix the foam
gasket to the back of the drive unit
chassis. Fix with the screws provided.
Add the grille and push in place
(clip the grille on screw’s heads).
To remove the grille, pull on the
tongue.
21 WX mounting
Fix the foam gasket to the back
of drive unit chassis, then fix with
the screws provided. Add the grille
and push in place (clip the grille on
screw’s heads) (fig. 3).
To remove the grille, pull on the
tongue.
Wiring
You must respect polarities between
subwoofer, amplifier and crossover
(fig. 2, 4).
25
English
