Focal Utopia Be Series - Utopia Be Active Kit; N°5; N°6 active kits wiring; N°7 active kit wiring

Utopia Be Active Kit
Active kits (N°5, 6, 7) are provided
without Crossblock crossover in
order to allow amplification with
active crossover. It is specially
adapted to numerous speakers
configurations.
N°5 / N°6 active kits wiring
Wire tweeter and woofer on active
crossover, then wire crossover to
amplifiers. Please bear in mind that
you must respect polarities (“+” to
“+”; “-” to “-”) (fig. 1).
N°7 active kit wiring
Wire tweeter and woofer on active
crossover, then wire crossover to
amplifiers. Please bear in mind that
you must respect polarities (“+” to
“+”; “-” to “-”) (fig. 2).
Speaker Recommanded minimal cutt-off
frequency (high-pass)
Recommanded maximal cutt-off
frequency (low-pass)
Tweeter Tbe 2.5kHz full
3 W2 Be 150Hz 6kHz
5 W2 Be 80Hz 4kHz
6 W2 Be 70Hz 4kHz
6 W3 Be 60Hz 1kHz
