3
Specifications
CAUTION
DO NOT INSTALL IN ANY FIREPLACE. NOT FOR EXTERIOR INSTALLATION!
DO NOT CONNECT TO OR USE IN CONJUNCTION WITH ANY AIR DISTRIBUTION DUCTWORK!
NOT TO INSTALL WITH MASONRY CHIMNEY SYSTEM.
• The authority having jurisdiction (such as municipal building department, fire department, fire prevention bureau, etc.) Should be
consulted before installation to determine the need to obtain a permit.
• Using make-shift compromises during installation can cause damage. Such installation is not covered under focus limited warranty.
• When this room heater is not properly installed, a house fire may result. To reduce the risk of fire, follow the installation instructions.
Contact local building or fire officials about restrictions and installation inspection requirements in your area.
CHARACTERISTICS
• Hearth 43 5/16 inch (1100 mm)
diameter
• Weight 214 lbs (97 kg)
• Flue diameter: 8 3/8 inch
(219mm)
- Length custom-made
• Flue weight: 10.6 lbs per foot
(16kg per meter)
• Standard plate weight of 42 lbs
(19 kg)
• 1/8 inch (3 mm) thick steel
• High heat resistant paint
• Stainless steel ball-bearing
revolving system for a 360°
rotation
• Fire screen
• Guaranteed efficiency with a
minimum flue length (interior
and exterior) of 14‘ (4250 mm)
(sol)
8’’ (200 mm)
Adapter
970 mm
(38
3
/16")
20"
(500mm)
Ø 8 1/16" id
(Ø 205 mm)
Ø 8 5/8" od
(Ø 219 mm)
220 mm
(8
11
/
16
")
Ø 1,100 mm
(43
5
/16")
805 mm
(31
11
/16")
1,775 mm
(69 13/16")
651 mm
(25
5
/8")
