7
C. WALL CLEARANCE WITH 360° ROTATION FIREPLACE
86 cm
75 cm
34’’
19’’
960 mm
38’’
D. WALL CLEARANCE WITH OPTIONAL ROTATION RESTRICTER
36 ’’
960 mm
920 mm
920 mm
480 mm
480 mm
5/16
36 ’’
5/16
Manufacturer specifications:
- When placed close to a non-
combustible wall leave a minimum
of 4” (101 mm) for proper ventilation
- To avoid premature aging of your
painted walls, only use mineral or
acrylic paints. With other paints,
above clearances apply.
- Fire clearance to glass (from hearth
edge): 20” (508 mm).
- Fire clearance to vinyl windows: refer
to window technical specifications.
IMPORTANT
Clearances may only be reduced by means approved by the regulatory authority.
