Focus DOMOFOCUS - Annex; Adjustable Suspension Plate

15
Annex
ADJUSTABLE SUSPENSION PLATE
78
3
/4"
(2.000 mm)
16
3
/8"
(416 mm)
2’’
(50 mm)
3
1
/8"
(80 mm)
Ø 8
7
/8" OD
(Ø 225 mm OD)
4’
(1.220 mm)
4’’
(100 mm)
Ø 12
3
/4" OD
(Ø 324 mm OD)
0 ≤ ß ≤ 12/12
(0 ≤ ß ≤ 45°)
Ø 13 1/4’’
(Ø 330/338 mm)
