Foley 653 ACCU-Master - Page 17

17






120 VAC 20 AMP
STANDARD PLUG FOR
NORTH AMERICA.
FIG.10
FOR 20 AMP RATED LARGE MACHINES










USE ONLY A QUALIFIED
ELECTRICIAN TO
COMPLETE THE

FIG. 11
H2, H3, H4, H7, H8 and H9.
X3 as
A

14 G. (2.5MM) GREEN
WITH YELLOW STRIPE
GROUNDWIRE TO BE
ADDED.
GREEN WITH YELLOW STRIPE
GROUND WIRE
GREEN WITH YELLOW STRIPE
GROUND WIRE
BROWN
LIGHT BLUE NEUTRAL
LIGHT BLUE
NEUTRAL
BROWN
POWER IN 230V, 1PHASE
POWER OUT 110V, 1PHASE
INSTALLATION INSTRUCTIONS
