Follett 12 - Wall Mounting Dimensions; Wall Mount Side View

8 12CI400A • 12HI400A 220 V 60 Hz/230 V 50 Hz Dispensers
minimum distance to
sink front
493 mm (19.375 " )
826 mm
(32
" )
575 mm
(22.625
" )
597 mm (23.5 " )
470 mm (18.5 " )
Fig. 6 – Wall mounting dimensions
Caution: Do NOT rest dispenser weight on bottom
of support bracket.
!
Fig. 7 – Wall mount side view
Installing wall mount dispensers
bottom of dispenser
outline of
dispenser
77 mm (3")
(14")
(7")
12 mm (.437")
356 mm
178 mm
36 mm
(1.4")
331 mm (13")
166 mm
(6.5")
204 mm (8")
77 mm (3")
407mm (16")
254 mm (10")
