Force FS Series User Manual

Mount Wall Bracket and Door Bracket
Wall Bracket – Close the garage door and measure the garage door
width at the top and mark the center. Locate and mount the wall
bracket 2 cm - 15 cm above the door on the inside wall.
(Depending on the actual installation space).
Door Bracket – Attach the door bracket to a structural part of the
door as close to the top edge as possible.
Figure 7
F
F
Figure 4
Figure 5
Figure 6
34

Force FS Series Specifications

General

Drive System	Chain Drive
Horsepower	1/2 HP
Frequency	60 Hz
Speed	7 inches per second
Battery Backup	No
Voltage	120V
Remote Controls Included	2
