Force FS Series User Manual

Attach warning label
Attach the warning about the risk of entrapment in a permanently prominent, clean place. For
example, near the permanently installed buttons used to open and close the garage door
opener.
The opener is equipped with a manual release cord to disengage the shuttle and enable
moving the door by hand while holding the handle down (Figure 17). Pull on the handle to
disengage the shuttle. To re-engage the door simply run opener in automatic mode or move
door by hand until the trolley engages in the chain shuttle.
In situations that a pedestrian door is not installed or available (2nd entrance to garage), it
is recommended that an external disengagement device should be fitted (not supplied)
(Figure 18).
MANUAL DISENGAGEMENT
Figure 17
Figure 18
42
