FORCE1 RC
10
THROTTLE MODE SELECTION
4 MODES
Your transmitter allows for left or right-hand throttle in a total of 4
different modes, depending on your preference.
To change the throttle mode press and hold the top-right button for 3
seconds (Fig. 3). The mode number is shown on the LCD screen (Fig. 4).
Keep pressing to cycle through modes, but note: Mode 2 is the default.
NOTE
Mode selection must occur when your transmitter is in signal connection
and the transmitter light is blinking.
ROTATE
LEFT/RIGHT
LEFTWARD/
RIGHTWARD
ROTATE
LEFT/RIGHT
LEFTWARD/
RIGHTWARD
FORWARD
THROTTLE
THROTTLE
FOREWARD
LEFTWARD/
RIGHTWARD
ROTATE
LEFT/RIGHT
LEFTWARD/
RIGHTWARD
ROTATE
LEFT/RIGHT
BACKWARDS
BACKWARDS
MODE 1
MODE 3
MODE 2
MODE 4
THROTTLE
FOREWARD
BACKWARDS
FORWARD
THROTTLE
BACKWARDS
FIGURE 3
THROTTLE
MODE DISPLAY
FIGURE 4
