Using a manual 4WD system (if equipped)
2H (2WD High) – Power to the rear wheels only; used for street and
highway driving.
4H (4WD High) – Used for extra traction such as in snow or icy roads
or in off-road situations. Not intended for use on dry pavement.
N (Neutral) – No power to either front or rear wheels.
4L (4WD Low)– Uses extra gearing to provide maximum power to all
four wheels at reduced speeds. Intended only for off-road applications
such as deep sand, steep grades or pulling heavy objects. 4L (4WD Low)
will not engage while the vehicle is moving; this is normal and should be
no reason for concern. Refer to Shifting to/from 4L (4WD Low) for
proper operation.
Shifting between 2H (2WD high) and 4H (4WD high)
• Move the transfer case lever between 2H (2WD High) and 4H (4WD
High) at a stop or any forward speed.
Note: Do not perform this operation if the rear wheels are slipping.
Shifting to/from 4L (4WD Low)
1. Bring the vehicle to a complete stop.
2. Depress the brake.
3. On vehicles equipped with an automatic transmission, place the
transmission in N (Neutral); on vehicles equipped with a manual
transmission, depress the clutch.
4. Move the transfer case lever through N (Neutral) directly to the
desired position. The 4WD LOW indicator will illuminate once the
transfer case has engaged.
• If the transfer case does not engage, repeat steps 1 through 4.
2H
4H
4L
N
Driving
124
