3.0L
and
4.0L
engines
(if
equipped)
The
high-current
fuses
are
coded
as
follows:
Fuse/Relay
Location
Fuse
Amp
Rating
Power
Distribution
Box
Description
1
50A**
I/P
fuse
panel
2
50A**
Amplifier
(T
remor
audio
system
only)
3
—
Not
used
4
—
Not
used
5
—
Not
used
6
50A**
Anti-lock
Brake
System
(ABS)
pump
motor
7
30A*
Powertrain
Control
Module
(PCM)
8
20A*
Power
door
locks,
Remote
entry
9
—
Not
used
10
—
Not
used
11
50A**
Starter
relay
,
Ignition
switch
12
20A*
Power
windows
Roadside
Emergencies
159
158
160
