Fuse/Relay
Location
Fuse Amp
Rating
Passenger Compartment Fuse
Panel Description
10 7.5A Speed control servo/amplifier
assembly, Generic Electronic
Module (GEM), Shift lock
actuator, Turn signals, 4x4
11 7.5A Instrument cluster, 4x4, Main light
switch, Truck Central Security
Module (TCSM), GEM
12 — Not used
13 20A Brake pedal position switch
14 10A ABS control module
15 — Not used
16 30A Windshield wiper motor, Wiper
HI/LO relay, Wiper run/park relay
17 20A Cigar lighter, Data Link Connector
(DLC)
18 — Not used
19 25A Powertrain Control Module (PCM)
power diode, Ignition, PATS
20 7.5A GEM, Radio
21 15A Hazard flasher
22 20A Auxiliary power socket
23 — Not used
24 7.5A Clutch Pedal Position (CPP)
switch, Starter interrupt relay
25 — Not used
26 10A Battery saver relay, Auxiliary relay
box, Restraint Central Module
(RCM), Generic Electronic
Module (GEM), Instrument
cluster
27 — Not used
28 7.5A GEM, Radio
