Ford 2016 EXPLORER - Page 271

Protected componentsFuse amp ratingFuse or relay number
Not used.—23
Not used.—24
Not used.—25
Anti-lock brake system valves.
30A
2
26
Trailer tow battery charge relay power.
30A
2
27
Not used.—28
Run/start relay.—29
Not used.—30
Electric power-assisted steering.
10A
1
31
Anti-lock brake system module.
10A
1
32
Powertrain control module (ISPR).
10A
1
33
Blind spot information system.
10A
1
34
Adaptive cruise control.
Front view camera.
Rear camera.
Not used.—35
Blower motor relay.—36
Trailer tow battery charge relay.—37
A/C compressor clutch relay.—38
Horn relay.—39
Not used.—40
Rear blower motor.
40A
2
41
Not used.—42
Front blower motor.
40A
2
43
Voltage quality module bus.
50A
3
44
Electronic fan relay 1.
40A
3
45
268
Explorer (TUB), enUSA, First Printing
Fuses
