Ford 2016 EXPLORER - Page 273

Protected componentsFuse amp ratingFuse or relay number
Trailer tow left-hand and right-hand stop
and direction indicator lamps.
20A
2
70
Not used.—71
Heated/cooled seats.
30A
2
72
Driver seat module.
30A
2
73
Driver seat power.
Passenger seat power.
30A
2
74
Front wiper motor.
30A
2
75
Not used.—76
Not used.—77
3rd row power folding seat module relay.
30A
2
78
Starter relay.
30A
2
79
Not used.—80
Trailer tow back-up lamp relay.
10A
1
81
Not used.—82
Brake on/off switch.
10A
1
83
Not used.—84
2nd row USB charger (if equipped).
5A
1
85
Not used.—86
Not used.—87
Not used.—88
Not used.—89
Not used.—90
Not used.—91
Multi-contour seat module relay.
15A
1
92
270
Explorer (TUB), enUSA, First Printing
Fuses
