Protected componentsFuse amp ratingFuse or relay number
Instrument cluster.
7.5A
2
13
Smart data link.
Steering column control module.
Not used.—14
Smart datalink connector power.
10A
2
15
Heads up display.
Not used.—16
Electronic finish panel.
5A
2
17
Push button start switch.
5A
2
18
Ignition switch.
Key inhibit.
Transmission control switch (tow haul).
7.5A
2
19
Not used.—20
Terrain management switch.
5A
2
21
Heads up display.
Humidity sensor.
Occupant classification sensor.
5A
2
22
Delayed accessory power.
10A
1
23
Power windows.
Moonroof.
Folding mirror relay.
DC inverter.
Window/moonroof switch illumination.
Central lock relay.
20A
1
24
Left-hand front smart window motor.
30A
1
25
Door zone module.
Right-hand front smart window motor.
30A
1
26
Door zone module.
Moonroof.
30A
1
27
Sony amplifier - 10 channel.
20A
1
28
Sony amplifier - 14 channel.
30A
1
29
273
Explorer (TUB), enUSA, First Printing
Fuses
