Second row seats - Grand C-
MAX
WARNINGS
When folding or unfolding the seats,
take care not to get your fingers
caught between the seatback and
seat frame.
Rock the seat backwards and
forwards after moving to make sure
that it is fully engaged in its catch.
Make sure the rear of the seat is
free from obstruction when moving
it rearwards.
Note:
Fully lower the head restraint when
folding the seats. See Head restraints
(page 110).
Easy entry position
WARNING
Do not use the seat when it is in the
easy entry position.
Note:
You can move the outboard seats
forwards to allow access to the third row
seats.
1. Either pull the lever on the side of the
seat cushion or pull the strap at the
rear of the seat. The seat will move
forward.
2. Fold the seatback forward.
Folding the seatback forwards or
backwards
