Tipper Controls
13
TopHinged or TipThru:
Recommended for 'Fluid' loads:
•Sand
• Gravel
• Crushed concrete
• Type 1 aggregate
• Dry topsoil
• Wood shavings
BottomHinged or TipOver:
Recommended for loads consisting of
one or more large individual items:
• Logs
• Tree cuttings
• Clay
• White goods
• Furniture
If in doubt, always use the tipover mode.
Top Hinged / Tipthru mode:
If the load begins to jam or choke in the rear aperture created by the
tailboard hinging from the top, lower the body fully and clear the
obstruction. Do not continue to tip when a jam occurs.
Bottom Hinged / Tipover mode:
Always ensure that there is sufficient clearance for the tailboard to
hang without touching the ground, a minimum of 12" (300mm) is
recommended with the Tailboard in the lowered condition – body fully
laden and in the lowered position.
If a tow bar has been fitted, ensure that the tailboard has been fitted
with a protective guide (see Towing) to prevent it from jamming on the
tow hitch. If a guide is not installed the tailboard may be damaged.
WARNINGS
