19
Tipper Controls
Isolation Switch
Do not drive the vehicle with the Tipper Isolation Switch in the
‘ON’ position.
Description:
The Tipper Isolation Switch isolates the
tipping gear powerpack from the vehicle
electrical supply, preventing the system
from operating, also providing a safe
condition for vehicle maintenance.
Location:
The switch is located on the right of the
drivers seat base. Adjacent to the cab offside rear corner pillar.
Purpose:
To safely isolate the tipping gear electro hydraulic systems when the vehicle is
being driven or for service, maintenance and repair operations.
Use:
• Only switch ‘ON’ immediately
prior to the tipping operation.
• Do not drive the vehicle with
the switch in the ‘ON’
position, stop immediately
when safe to do so and turn
switch to ‘OFF’ position.
• Under all circumstances,
other than the tip operation
itself, the isolation switch
must always be set to the ‘OFF’ position.
WARNING
