23
Tipper Controls
Warning Buzzers
Description:
The Warning Buzzers provide an audible warning when the Tipper is being
raised or lowered. The warning buzzers also warn of the following:
The Handbrake has been released with the Isolator switched on.
The Hydraulic Body Latch has not engaged correctly.
The Auxiliary Battery voltage level is too low for Tipping.
Location:
Purpose:
External Warning Buzzer: 
The External Warning Buzzer sounds continuously as the Tipper is raised and
intermittently when lowered. It will continue until the Tipper is fully lowered and
locked down.
If the External Warning Buzzer continues with an intermittent sound when the
body is fully lowered, the hydraulic body latch will not have correctly 'latched' to
the underside of the body.
Refer to the Maintenance section to check the correct operation of the Latch.
Do not drive vehicle if warning buzzer fails to mute after body
has lowered.
The ‘External Buzzer is located on the
right hand side of the Tipper subframe
The ‘Internal’ Buzzer is located on the
Control Station adjacent to the drivers seat
WARNING
1 Way Hand Book Nov'14:11-12 Seat Transit 28/11/14 11:13 Page 26
