20
Tipper Controls
To Raise Body…
• Release Tailboard. (Refer to pages 1315)
• Lift Joystick to raise body. The external sounder will operate when
body is raising, continue lifting Joystick until body is fully raised or load
is deployed
• Release Joystick at any time whilst body is raising to stop tipping
To lower body…
• Press Joystick downwards to lower body. The external sounder will
operate with a different tone when lowering. Continue pressing Joystick
downwards until body if fully lowered.
• Release Joystick at any time whilst
body lowering.
Note: External sounder will cease
operating when body is fully down
and locked.
Emergency Stop…
• At any time, pressing the Emergency Stop Button will cease all
Tipper functions.
• Ensure it is safe to proceed before releasing emergency stop button.
Twist it clockwise, then reset power ‘ON’ switch.
Note: Subject to battery charge it may be necessary to run engine to
operate Tipper.
