Forest-Master FM4DDE - Parts List (FM4 DDE)

Forest Master Model: FM6DD/FM4DDE 23
Parts List
Part No. Description Qtv Part No. Description Qtv
1 Feed Hopper 1 45 Split Pin 1.6×20 2
2 Rubber Curtain 1 46 Axle Φ16×2 1
3 PP Plate 1 47 Φ16 Flat Washer 2
4 Rubber Curtain Fixed Plate 1 48 Φ16 Dome Cap 2
5 Rubber Curtain Fixed Bend Steel 1
6 Rubber Curtain Fixed Bolts M5×12 3
7 Rubber Curtain Flat Washer Φ5.0 12 50 Discharge Chute Bolt M6x12 2
8 Rubber Curtain Lock Nut M5 3 51 Hopper Bolt M6×23 1
9 Hopper Safety Plate 1 52 Drum Bolt 5/16-24×100 1
10 Hopper Rubber Gasket 1 53 Flat Washer Φ8×3.0 1
11 Hopper Round Tube End Cap 2 54 Key 1
55
Serrated Washer Φ8×0.8 2
56 Engine or Motor Fix Bolt M8×35 4
13 Spring Washer M5 2 57 M8 Lock Nuts 4
14 Drum Housing 1 58 /
/
15 Drum 1 59
Spring Washer Φ6 3
16 Drum Blade 2 60 Electric Motor
1
17 Drum Blade Bolt M10x25 4
19 Hopper Opening Micro Switch 1
22 Drum Housing Outer Plate 1
23 Drum Bearing 20×42×12 1
24 Bearing Circlip 1
25 Drum Housing Outer Plate End Cap 1
26 Bottom Blade 1
27 Drum Spacer Sleeve 1
30 M8 Spring Washer 5
31 M8×10Bottom Blade Flange Lock Bolts 2
32 M4×10 Micro Switch Box Fixed Bolts 2
33 Flat Washer Φ8×1.6 12
34 Discharge Chute 1
35 Discharge Chute Direction Flap 1
36 Discharge Chute Absorber Rubber 1
37 Discharge Chute Flap Bolt M6x10 4
38 Discharge Chute Flap Nut M6 4
39 M3×60 Discharge Chute Safety Bolts 2
40 M3 Discharge Chute Safety Nuts 2
41 Flat Washer Φ6×1.0 11
42 Base 1
43 Wheel 2
44 Front Foot Rubber Cap 2
49
Hopper and Output Chute Pivot Bolt
M8x110
2
12
Safety Plate and Rubber Curtain
Mounting Bolts M5X10
6
18 Hopper Opening Micro Switch Lower Box 1
20
Hopper Opening Micro Switch Upper
Cap
1
29
Drum Housing Outer Plate Mounting
Bolt M8x15
4
21
Micro Switch Box Upper Cap Bolts
M3×14
2
28 Drum Housing Mounting Bolt 5/16-24×20 4
