3-6
FORMULA
PERFORMANCE CRUISER/SUPER SPORT
CRUISER/SUPERSPORT
Item
Drive Unit Pump - STBD
Engine Compartment Blowers
Engine Compartment Hatch Handle
Engine Compartment Switch
Fire Extinguisher - Cabin
Fire Extinguisher - Cockpit
Fresh Water Dockside Hookup
Fresh Water Level Indicator
Fresh Water Pump
Fuel Tank Fill - PORT
Fuel Tank Fill - STBD
Helm Hydraulic Steering Fill
Hull Identification Number
Seacock - Air Conditioning Intake
Seacock - Generator Intake
Seacock - Macerator Discharge
Seacock - Manual Head Intake
Seacock - Raw Water Engine Intakes
Strainer - Air Conditioning Intake(s)
Strainer - Generator Intake
Strainer - Raw Water Engine Intakes
Telephone Dockside Inlet
Transom Shower
Trim Tab Pump
TV Antenna/Cable Switch
TV Signal Amplifier
Waste Deck Plate
Gray Water Manifold(s)
Gray Water Sump Tank
Location
D-2
D-1, D-2
B-2
C-3
A-5
A-2
D-1
A-5
A-5
A-3
D-3
N/A
D-1
B-3
C-3
B-2
N/A
B-3, C-3*
B-3
C-3
B-3, C-3*
D-1
A-1
D-1
A-4
A-4
A-1
A-1
B-4
Remarks
Engine compartment, STBD side, behind water htr
Engine compartment, STBD hull side
Engine hatch, FWD top edge
Helm, inboard of steering wheel, above ignition
Cabin, lower galley, aft cabinet
Cockpit, beneath wet bar
Swim platform, STBD side
Cabin, galley - lower cabinet, aft
Cabin, beneath V-berth bed base
Deck, PORT side, aft of radar arch base
Deck, STBD side, aft of radar arch base
N/A
Aft STBD corner, beneath rub rail
Engine compartment, FWD of PORT motor
Engine compartment, FWD of STBD motor
Engine compartment, FWD of PORT engine
N/A
Engine compartment, FWD of either motor
Engine compartment, FWD of PORT motor
Engine compartment, FWD of STBD motor
Engine compartment, FWD of either motor
Swim platform, STBD side
Deck, PORT side near transom entry door
Engine compartment, STBD hull side
Cabin, galley - lower cabinet, aft
Cabin, galley - lower cabinet, aft
Swim platform, PORT side
Engine compartment, PORT side, transom
Cabin, beneath entry steps, remove step (floor
access lid)
* Mercury horizon closed water cooled motors only
