7. Right Knob: It is used to adjust the following welding parameters:
a. in STICK, “SMAW”Mode it adjusts the over-current value of the electric arc (Hot Start),
variable from 0 to 50% on the current value adjusted with the Left Knob (8).
b. In TIG, “GTAW” Mode is not active.
c.
In MIG, “GMAW” Manual Mode (2T/4T) it adjusts arc voltage value (no load) from 10V to 24V.
d. In MIG, “GMAW” Synergic Mode (2T/4T) it adjusts the % of welding power available
(depending on the input voltage) variable from 0 to 80% (maximum power).
8. Left Knob, It is used to adjust the following welding parameters:
a. In STICK, “SMAW”Mode it adjusts the current value from a minimum of 20Amp to a
maximum of 80 Amp. If Remote is selected with switch (20) the left knob is not active.
b. In TIG, “GTAW” Mode, it adjusts the current value from a minimum of 5 Amp to a
maximum of 100Amp. If Remote is selected with switch (20) the Left knob is not active.
c. In MIG, “GMAW” Manual Mode (2T/4T) it adjusts the wire speed from 1 (minimum wire
feeder speed) to 80 (maximum speed). If Remote is selected with switch (20) the Left knob is
not active.
d. In MIG, “GMAW” Synergic Mode (2T/4T) it adjusts the wire speed from 1 (minimum wire
feeder speed) to 80 (maximum speed). If Remote is selected with switch (20) the Left knob is
not active.
9. Negative Dinse socket:
a. In STICK Welding, “SMAW” for the connection of the ground cable connector (check for
correct polarity for the electrode you are going to use, refer to the information on its box);
b. In TIG Welding, “GTAW” for the TIG torch cable connection (Torch trigger connection must
be connected to the 7 pin connector – 12 -)
c. In MIG Welding, “GMAW” (with gas) for the connection of the ground cable connector
10. Positive Dinse socket:
a. In STICK Welding, “SMAW”, for the connection of the ground cable connector (check for
correct polarity for the electrode you are going to use, refer to the information on its box);
b. In FLUXCORE WIRE Welding, “FCAW”, for the connection of the ground cable connector.
11. Euro connect for attaching the MIG torch cable. In FLUXCORE WIRE Welding, “FCAW”,
change the polarity of the Euro socket using the terminals on the Polarity Change Board
located inside the wire spool compartment above the wire feeder -19-). To attach the Spool
Gun, remove the standard MIG torch from the Euro Connect and connect the Spool Gun.
Also connect the Spool gun control lead to the seven pin connector (12) on the front of the
cabinet and switch the Local / Remote switch (20) to the Remote position.
12. 7 pin connector it is used when:
a. in STICK, “SMAW”Mode when Remote is selected with switch (20) for connecting the foot
remote control;
b. in TIG, “GTAW” Mode when Local is selected with switch (20), for connecting the TIG torch
trigger control cable;
c. in TIG, “GTAW” Mode when Remote is selected with switch (20) for connecting the
foot pedal remote control; in this case the TIG torch trigger control cable has to be
disconnected;
d. In MIG Welding, “GMAW”, Manual and Synergic when Remote is selected with switch
(20), for connecting the Spool gun torch 7 pin male connector;
13. Input power cable
14. ON/OFF Switch
