NO. PART NUMBER ITEM DESCRIPTION QTY.
01 21690226K Door latch (1pc pack)
1
02 05000274 Left panel with silk screen and labels
1
03 04600437 Kit spool holder with ring for 5kg spool
1
04 22200020 Switch 3a
1
05 21690737 Knob
1
06
33740582
9005
Metal box for front panel pcb protection
1
07 05000280 Dividing panel with labels
1
08 44410068 Wire feeder plast/all d.37 Rul.06-09
1
09 23005381K Wire guide tube d.2X5 l=71 1pc pack
1
10 23005520 Mig gun euro connection l=17
1
11 04600145 Motor d.37 + Pinion
1
12 21690556 Torch connection cover
1
13 04600433 Assembly frame + caps
1
14 21690797 Knob with cap and index
1
15 21690796 Knob with cap and index
1
16 21690713 Spacer for plastic frame
1
17 22735551 Front panel pcb pfc with remote control
1
18 21800067 Knob with threaded bushing
1
19 04600412 Kit gas/no gas change board
1
20 21690733 Foot h=144
1
21 22735375 Slope external regulation pcb
1
22 22225332 Relay 40a 24vdc
1
23 22910004K Hose tail d.6 1/8"M 1 pc pack
1
24 22900009 Solenoid valve 9w 24v dc 1/8"ff
1
25 05000278 Rear panel
1
26 22910110 Female gas connector 1/8"gas - 5/8"unf
1
27 22200047 Bipolar black switch w/protection
1
28 20220173
Inp.Power cable3x12awg4.5M+50a6-
50p plug
1
29 21605040K Prensaestopa 2 piezas d.20
2
Tools and Spare Parts List
NO. PART NUMBER ITEM DESCRIPTION QTY.
30 21690589 Fan spacer
1
31
33700415
9005
Bottom panel
1
32 40211429 7 Pin connector cable assembly
1
33 77650400 Front panel label 190mp
1
34 05000270 Front panel 190mp forney w/silk screen
1
35 22100002K
Fem.Dinse plug 25sqmm cx30 (1 pc
pack)
1
36 26075013 Hall probe ync-200a
1
37 22735443
Power board mig 160a/mma pfc
230/115v
1
38 21690225K Plastic hinge for door 20x30 2pcs pack
2
39 05000261 Right cover panel with silk screen
1
40
33740579
9005
Torch wrapper
1
41 21600067 Handle for torch wrapper
1
42 21060152K Flat-key 3x3 l=20 1pc pack
1
43 33805071K
Feed roll d.30 0,6-0,9Mm mot2r 1 pc
pack
1
44 33810136 Feed roll secure knob
1
45 23000448
Mig torch 14mm2 3mt tweco 1 euro
connect
1
46 43210188
Ground cable 16 mm2 mt.3 300Amp
dn25
1
47 22100001K Dinse plug 25mm2 cx20 1 pc pack
1
48 22110033K Earth clamp 300a zinc-coated 1 pc pack
1
49 43205028K
Weld.Cable 16 sqmm m 3 w/c.202/
Dn25 1pc
1
50 22110010K Electrode holder art.202 1 Pc pack
1
51 22905101
Gas reducer 2 man. Cga580-5/8"
unf-2b
1
52 30900035 Black gas hose 3 meter
1
53 20220158
Adapter cord stw awg12/3c 1m
6-50r/5-20p
1
