Forney 190 - Tools and Spare Parts List

22
WWW.FORNEYIND.COM
NO. PART NUMBER ITEM DESCRIPTION QTY.
01 85005 Door latch (1pc pack) 1
02 84008 Left panel with silk screen and labels 1
03 85541 Kit spool holder with ring for 5kg spool 1
04
85561 Wire feeder plast/all d.37 Rul.06-09 1
05 85207 Motor d.37 + Pinion 1
06 84978
4 Lobes d.30 Hand-wheel m8bush 2pcs
pack
2
07 84001 Mig gun euro connection l=32 1
08 85204 Kit gas/no gas change board 1
09 85575 Switch knob d.38 Black 1
10 85554 Black knob d.38 For potentiom. + Pointer 1
11 85706 Assembly frame + caps 1
12 21690713 Spacer for plastic frame 1
13 84033 Torch grommet for euro connection 1
14 85525 P.C.Board e0592.1R 110v + fuse"csa" 1
15 05000279 Dividing panel with labels 1
16 85257 Rectifier pms 30b f type 1
17 85540
Solenoid valve 11va 110v 60hz 1 pc
pack
1
18 05000275 Rear panel 1
19 22910110 Female gas connector 1/8"gas - 5/8"unf 1
20 85230
1Pck input cable 3xawg1 4
2,25m+us5/15plug
1
21 84066
Cable clamp+ring nut, hole d. 20, 2Pcs
pack
2
22 85201 Complete fansp.16 110V 1
23 84010 Cable holder 1
Tools and Spare Parts List
NO. PART NUMBER ITEM DESCRIPTION QTY.
24 85573 Thermostat 100ø 10a1 pc pack 1
25 84006
Transformer 1ph mig 60hz 115v 40x72
al
1
26 84002 Plastic hinge for door 20x30 2pcs pack 2
27 85256 Contactor lx0 110v 10a 4na (cn-11) 1
28 84080 Choke d.4,3 40X25 al 1
29
33700414
9005
Bottom panel 1
30 85539 Rotary switch ca20 cm14 1
31
05000267 Front panel 140 mig forney w/silk screen 1
32 84914 Green on/off switch 16a-250v 1 pc pack 1
33 85276 Earth cable 10gr.Mmq mt. 2 (Pack.1) 1
34 85011 Earth clamp 300a zinc-coated 1 pc pack 1
35 84007 Right cover panel with silk screen 1
36 84003 Torch wrapper 1
37 84004 Handle for torch wrapper 1
38
85520 Flat-key 3x3 l=20 1pc pack 1
39 85511
Feed roll d.30 0,6-0,9Mm mot2r 1 pc
pack
1
40 85515 Feed roll secure knob 1
41 85500
Mig torch 14mm2 3mt tweco 1 euro
connect
1
42 85662
Gas reducer 2 man. Cga580-5/8"
unf-2b
1
43 30900035 Black gas hose 3 meter 1
