4. Wi-Fi router
AIP-W525H Wi-Fi router (by Alfa Network) is supplied in the kit of LaserPro laser tag. The
routing device is developed on the base of RTL8196C network processor and supports IEEE
802.11n standard enabled to provide bitrate up to 300 Mbit/s.
The router is equipped with external power adapter (12 V, 1A), UTP cable and two
antennas with absolute gain of 5 dBi.
Reset button sets device to factory settings. WPS button (for operating system
Windows 7 or up) allows rapid connecting with protected Wi-Fi network. Instead of
entering network security key, it is enough to press this button.
There are 4 LAN ports and WAN port (to connect provider’s cable), as well as
connector for power adapter on the connection panel.
The device is supplied being fully customized for operation with the software and
hardware used with LaserPro laser tag equipment.
If own device is used or there is a need to perform reconfiguration, follow
instructions attached to this model as well as the corresponding section of this manual
(p.13).
