Thank you for purchasing the FortiWiFi 60CM-3G4G. The
FortiWiFi 60CM-3G4G multi-threat security appliance offers you unmatched
performance, flexibility, and security for your remote, branch, or small office
network.
Your box contains the following:
FortiWiFi 60CM-3G4G
QuickStart Guide
USB Cable
Ethernet Cable
Power Cable and Adapter
2 WiFi, 2 3G, and 2 4G Antennae
Wall-mount Template
FortiWiFi-60CM-3G4G
QuickStart Guide
QuickStart Guide
USB Cable
Ethernet Cable
Power Cable
Power Adapter
The unit should be placed farther than 75mm on each side from a heat source. If you
are mounting more than one unit, place them in a vertical row to provide better ventila-
tion.
Required Materials:
Drill bit: Size is determined by the screw size.
Anchors: Two for mounting on dry-wall, plasterboard, or gyprock.
Screws: Two appropriate for anchors. Maximum diamter of 3.5mm.
Instructions:
1. Tape this template to the wall in the desired location.
2. Mark the position of the drill holes on the wall.
3. Drill two holes.
4. Insert anchors into drilled holes.
5. Insert the screws into the anchors. Screws should protrude 5mm out of wall.
6. Place FortiWifi-60C key holes over the screws and slide the unit down into position.
The FortiWifi-60C can be placed in either position shown below.
Wall-Mount Template
FortiWifi-60C
Drill hole Drill hole
Wall-mount
Template
4
G
_
2
4
G
_
1
2 4G
Antennae
W
I
F
I
W
I
F
I
2 WiFi
Antennae
3
G
_
2
3
G
_
1
2 3G
Antennae
1. Package Contents
