Fortinet FortiGate FortiGate-800

NAT/Route mode installation Configuration example: Multiple connections to the Internet
FortiGate-800 Installation and Configuration Guide 51
Figure 9: Example multiple Internet connection configuration
Configuring ping servers
Use the following procedure to make gateway 1 the ping server for the external
interface and gateway 2 the ping server for the DMZ interface.
1 Go to System > Network > Interface.
2 For the external interface, select Modify .
• Ping Server: 1.1.1.1
• Select Enable Ping Server
•Select OK
3 For the DMZ interface, select Modify .
• Ping Server: 2.2.2.1
• Select Enable Ping Server
•Select OK
External
Port3
Internal
FortiGate-800
Internal Network
Internet
192.168.1.99
2.2.2.2
Gateway #1: 1.1.1.1
External Network #1
100.100.100.0
External Network #2
200.200.200.0
Gateway #2: 2.2.2.1
1.1.1.2
192.168.1.0
ISP1
ISP2
Esc Enter
CONSOLE
INTERNAL EXTERNAL DMZ HA 123
4USB
8
PWR
