Transparent mode configuration examples Transparent mode installation
Figure 11: Default route to an external network
General configuration steps
1 Set the FortiGate unit to operate in Transparent mode.
2 Configure the Management IP address and Netmask of the FortiGate unit.
3 Configure the default route to the external network.
Internal Network
DMZ
Internet
Upstream
Router
Gateway IP 192.168.1.2
Management IP 192.168.1.1
DNS
FortiResponse
Distribution
Network (FDN)
Management
Computer
FortiGate-800
Esc Enter
CONSOLE
INTERNAL EXTERNAL DMZ HA 123
4 USB
8
PWR
To Next Page
