70 Fortinet Inc.
Transparent mode configuration examples Transparent mode installation
Figure 13: Static route to an internal destination
General configuration steps
1 Set the unit to operate in Transparent mode.
2 Configure the Management IP address and Netmask of the FortiGate unit.
3 Configure the static route to the management computer on the internal network.
4 Configure the default route to the external network.
Management Computer
172.16.1.11
Internal Network A
Internal Network B
DMZ
Internet
Upstream
Router
Internal
Router
Gateway IP 192.168.1.2
Management IP 192.168.1.1
FortiResponse
Distribution
Network (FDN)
Gateway IP
192.168.1.3
DNS
FortiGate-800
Esc Enter
CONSOLE
INTERNAL EXTERNAL DMZ HA 123
4 USB
8
PWR
