01: Output voltage settings
02: Frequency Converter enable/disable
03: Output frequency settings
04: ECO enable/disable
Interface Setting
Parameter 3: Output voltage
For 200/208/220/230/240 VAC, you may choose any of the
following output voltages in parameter 3:
200: The output voltage is 200VAC
208: The output voltage is 208VAC
220: The output voltage is 220VAC
230: The output voltage is 230VAC
240: The output voltage is 240VAC
For 100/110/150/120/127 VAC, you may choose any of the
following output voltages :
100: The output voltage is 100VAC
110: The output voltage is 110VAC
115: The output voltage is 115VAC
120: The output voltage is 120VAC
127: The output voltage is 127VAC
Interface Setting
Parameter 2 & 3: Activates or cancels the converter mode
CF ENA: Enable converter mode
CF DIS: Disable converter mode
Interface Setting
Parameter 2 & 3: Output frequency setting.
Use this menu to define the initial frequency on battery mode:
BAT 50: The output frequency is set to 50Hz
BAT 60: The output frequency is set to 60Hz
If the converter mode is enabled, the following options
will be available:
CF 50: The output frequency is set to 50Hz
CF 60: The output frequency is set to 60Hz
Interface Setting
Parameter 3: Activates or cancels the ECO mode:
ENA: ECO mode enabled
DIS: ECO mode disabled
