Foscam C2M User Manual

6
2 Default Parameters
Default network parameters
IP address: obtain dynamically
Subnet mask: obtain dynamically
Gateway: obtain dynamically
3 Specification
ITEMS
C2M V6
Image Sensor
Sensor Type
High Definition Color CMOS Sensor
Display Resolution
2.0Megapixels(1920x1080)
Min. Illumination
0 Lux (With IR Illuminator)
Lens
Lens Type
f.2.8mm; F2.0
Angle of view
Diagonal: 108.8°, Horizontal: 98.2°, Vertical: 53.1°
Video
Image Compression
H.264+/H.264
Resolution
1080P(1920x1080) 25fps,720P(1280 x 720), VGA(640 x 480)
Stream
Dual stream
Image Adjustment
The brightness, contrast, saturation, sharpness are adjustable
Flip Image
Flip and mirror
Infrared Mode
Automatic or manual
Night Visibility
9pcs IR-LEDs, night vision range up to 8 metres
Audio
Input/Output
Supports Two-way Audio
Audio Compression
PCM/AAC
Network
Ethernet
One 10/100Mbps RJ45 port
Wireless Standard
2.4G/5G dual-band, IEEE802.11b/g/n/ac
Data Rate
IEEE802.11b: 11Mbps(Max.);
IEEE802.11g: 54Mbps(Max.);
IEEE802.11n: 150Mbps(Max.).
IEEE802.11ac: 433Mbps(Max.).
Wireless Security
WPA, WPA2
Wireless Setup
Supports QR Code+Wave wireless setup
Network Protocol
IP, TCP, UDP, SMTP, FTP, DHCP, RTSP
Remote Access
P2P
System
Requirements
Operating System
Microsoft Windows (Foscam VMS), MacOS (Foscam VMS), Android
(Foscam app), iOS (Foscam app)
Other Features
Motion Detection
Alarm via E-Mail, FTP and Foscam app when an event is detected
Sound Detection
Alarm via E-Mail, FTP and Foscam app when an event is detected

Foscam C2M Specifications

General

Type	IP security camera
Certification	CE
Languages support	-
Virtual assistant	Amazon Alexa
Placement supported	Indoor
Connectivity technology	Wireless
Infrared (IR) cut-off filter	Yes
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Built-in SSD	No
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
Mobile operating systems supported	Android, iOS
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows XP
Number of cameras	1
Sensor type	CMOS
Optical sensor size	1/2.9 \
Total megapixels	2 MP
Maximum resolution	1920 x 1080 pixels
Video formats supported	H.264
Minimum illumination	0 lx
Maximum aperture number	2.8
Minimum aperture number	2.6
Night vision distance	8 m
Security algorithms	WPA, WPA2, WPS
Intelligent Video Surveillance (IVS) system features	Abnormal sound detection, Human detection
Audio output channels	2 channels
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	20 - 85 %
DC output current	1 A
DC output voltage	5
Power source type	DC
Power consumption (typical)	4.8 W
Sustainability certificates	Federal Communications Commission (FCC), RoHS, WEEE
Form factor	Bullet
Mounting type	Ceiling/wall
Product color	White

Weight and Dimensions

Depth	70 mm
Height	120 mm
