System
Requirements
Operating System
Microsoft Windows 2000/XP, Vista 7,8;
Mac OS
Browser
Microsoft IE8 and above version or compatible browser;
Mozilla Firefox;
Google Chrome;
Apple Safari.
Other Features
Motion Detection
Alarm via E-mail, upload alarm snapshot to FTP
User Accounts
Three levels user role
Firewall
Supports IP Filtering
Reset
Reset button is available
Power
Power Supply
DC 12V / 1.0A
Power Consumption
5 Watts (Max.)
Physical
Dimension (L * W * H)
97mm * 67mm * 64mm / 3.8in * 2.6in * 2.5in
Net Weight
255g / 0.6lb
Environment
Waterproof
IP66
Operating Temperature
-10ºC ~ 60ºC (14ºF ~ 140ºF )
Operating Humidity
10% ~ 80% non-condensing
Storage Temperature
-20ºC ~ 60ºC (-4ºF ~ 140ºF )
Storage Humidity
0% ~ 90% non-condensing
Certification
FCC, CE, RoHS, WEEE,IP66
ITEMS
G4P G4
Image Sensor
Sensor
High Definition Color CMOS Sensor
Display Resolution
2560*1440 (4.0M Pixels)
Min. Illumination
0 Lux (With IR Illuminator)
Lens
Lens Type
Glass Lens
focal length
f:4mm
Aperture
F2.0
Angle of view
Horizontal: 89º, Diagonal: 112º
Video
Image Compression
H.264
Image Frame Rate
30fps (60Hz), 25fps (50Hz), downward adjustable
Resolution
2k(2304x1536)
20fps,3MP(1204x1440)25fps,1080P(1920x1080)
25fps,720P(1280 x 720), VGA(640 x 480),QVGA(320 x
240)
Stream
dual stream
Image adjustment
The hue, brightness, contrast, saturation, sharpness are
adjustable
Flip image
flip and mirror
Infrared mode
Automatic or manual
IR range
With 30pcs IR-LED, IR LEDs for IR range up to 20m /
