Foscam R2C - Default Parameters; Specifications

67
6.2 Default Parameters
Default network Parameters
IP address: obtain dynamically
Subnet mask: obtain dynamically
Gateway: obtain dynamically
Username and password
Default admin username: admin with a blank password
6.3 Specifications
ITEMS
R2C R2M
Image Sensor
Sensor Type
1/2.7'' CMOS
Display Resolution
1920 x 1080 (2.0 Megapixels)
Frame Rate
25fps
Min. Illumination
0 Lux (With IR Illuminator)
Lens
Lens Type
f:4mm,F:2.0
Angle of View
Horizontal:90°
Diagonal :100°
IR Range
13pcs IR-LEDs, IR Range up to 10m(32.8ft)
Video
Image Compression
H.264
Resolution
1080P(1920x1080) ,720P(1280 x 720), VGA(640 x 480),
QVGA(320 x 240)
Stream
dual stream
Image adjustment
The hue, brightness, contrast, saturation, sharpness are
adjustable
Flip image
flip and mirror
Infrared mode
Automatic or manual
manual Pan/Tilt Angle
Horizontal:350° & Vertical: 100°
Audio
Input/Output
Supports two-way audio
Built-in Mic & Speaker
Audio Compression
PCM/G.726
Network
Ethernet
One 10/100Mbps RJ45 port
Wireless Standard
IEEE802.11b/g/n
Data Rate
IEEE802.11b: 11Mbps(Max.);
IEEE802.11g: 54Mbps(Max.);
IEEE802.11n: 150Mbps(Max.).
Wireless Security
WPA, WPA2
Wireless Setup
Supports EZLink wireless setup
Network Protocol
IP、TCP、UDP、HTTP、HTTPS、SMTP、FTP、DHCP、RTSP、
WPS、ONVIF
