Installa on Instruc ons
Installa on of these units should be carried out by a competent person and appropriate codes of prac ce
adhered to, thus ensuring safe installa on.
Removal Of The Panels From The Pallet
The cabinets are of modular construc on with the wall panels and ancillary items delivered with retaining
shrink-wrap. This exterior should be removed, which a er cu ng the bands will allow all the components
to be removed and then checked for damage before placement in a convenient area for assembly.
There could be more than one crate – so check each one as above.
Installa on Of Panels And Equipment
The following instruc on is suggested as a method of installa on.
The ceiling panel is supplied with the refrigera on system / heater assembly pre-fi ed, ready for
installa on, once the wall panels are erected.
The cabinets are fl oorless and therefore require fi ng to a clean level fl oor.
The wall panels are a ached to the fl oor by inser ng them into PVC ‘U’ Channel. This is supplied cut and
mitred and should be fi ed to the fl oor prior to installa on
Loca on
Flat, level, clean, sound surface.
This appliance has a top mounted system and will need a minimum of 300mm clearance above the unit.
Panel Layout and Dimensions
